HY HassCR150 fully automatic ultrafiltration (concentration and liquid exchange) system

HY HassCR150 fully automatic ultrafiltration (concentration and liquid exchange) system

Introduction:

- Multi channel: A single computer controls multiple instruments, which can be parallel or serial
- Regular computers: up to 16 units
- Flow rate range: 0~2500mL/min customizable
- Pressure resistance: 0~70psi
- Single wavelength 280: ± 6AU
- Attachment: Dual conductivity and dual liquid level detection Scope of application

Scope of application

Combined with the Pellicon module, fully automated protein purification and concentration can be carried out, from experimental to industrial levels, with only the need to replace the inlet and outlet pipelines. This system can be used for liquid exchange and preparation.

Message inquiry Online customer service contact

产品参数应用示例

项目	参数	备注
外观
泵	流速范围： 0~150mL/min（默认16#）。耐压： 0.5Mpa（70psi）。流速准确度：±2~10%，流速精度：RSD< 4 %。转速分辨率： 1rpm。接口：网口通信压力传感器：耐压范围(0~10Mpa) 精度：±0.025Mpa 清洗：自动清洗	默认单泵500mL/min，更换硅胶管，最大可达2500mL/min
检测器	单波长检测器280nm	可选其他波长
电导1	电导0-999 mS/cm，分度0.001，基本误差±1.0% 自动温度补偿	默认
电导2	电导0-999 mS/cm，分度0.001，基本误差±1.0% 自动温度补偿	默认
通信方式	TCPIP(100M网口)	默认
配件盒子	管路接头等配件	默认
工作站	中英文界面，包含仪器控制、方法编制、数据处理和打印报告功能，用户和实验结果数据库，加密数据库管理用户和实验结果，支持峰积分、定量计算、审计追踪、scouting、通道scouting、方法编程功能和8通道联合工作	默认
A泵入口阀	7通道高压旋转阀	6通道 +1公共通道(7通道)
气泡传感器入口A	外置超声波	默认
液位检测器1	响应时间<500ms	默认
液位检测器2	响应时间<500ms	默认
压力传感器1	P1,柱前, 0~10Mpa	默认
压力传感器2	P2,柱后, 0~10Mpa	默认
压力传感器3	P3,回流后, 0~10Mpa	默认
加压装置	默认AP1，AP2 两个	默认
浓缩溶液范围	根据管路及配置10mL ~ 200L及更大	默认
扩展接口	1个级联电源、2个网口， 2个DB9口，3个DSub
可选通道数	1~12通道	默认1通道
通信指令	自定义优化指令设计，对外提供通过测试开发库包含.net格式、及C/C++DLL格式，提供示例源码	可用于二次开发。
人机接口	win7/win10/win11	配置：Intel i3及以上处理器，内存>=8GB, 硬盘>=256GB 显示：1920x1080
供电	110v~220V(交流)，±5%
温度	-10~40℃，无冷凝
